深沟球轴承
| 轴承型号 | 内径 | 外径 | 厚度 | 动负荷 | 静负荷 | 疲劳载荷 | 参考转速 | 极限转速 | 轴承类型 | 图片 |
|---|---|---|---|---|---|---|---|---|---|---|
| 6024-2Z/VA208 | 120mm | 180mm | 28mm | 88.4kN | 80kN | RPM | RPM | 30RPM | 深沟球轴承 |  |
| 6022-2Z/VA208 | 110mm | 170mm | 28mm | 85.2kN | 73.5kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6020-2Z/VA208 | 100mm | 150mm | 24mm | 63.7kN | 54kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6220-2Z/VA208 | 100mm | 180mm | 34mm | 127kN | 93kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6220-2Z/VA228 | 100mm | 180mm | 34mm | 127kN | 93kN | RPM | RPM | 60RPM | 深沟球轴承 | |
| 6219-2Z/VA228 | 95mm | 170mm | 32mm | 114kN | 81.5kN | RPM | RPM | 60RPM | 深沟球轴承 | |
| 6219-2Z/VA201 | 95mm | 170mm | 32mm | 114kN | 81.5kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6218-2Z/VA228 | 90mm | 160mm | 30mm | 101kN | 73.5kN | RPM | RPM | 70RPM | 深沟球轴承 | |
| 6217-2Z/VA208 | 85mm | 150mm | 28mm | 87.1kN | 64kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6316-2Z/VA208 | 80mm | 170mm | 39mm | 130kN | 86.5kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6216-2Z/VA208 | 80mm | 140mm | 26mm | 72.8kN | 55kN | RPM | RPM | 40RPM | 深沟球轴承 | |
| 6215-2Z/VA201 | 75mm | 130mm | 25mm | 68.9kN | 49kN | RPM | RPM | 40RPM | 深沟球轴承 | |
| 6315-2Z/VA208 | 75mm | 160mm | 37mm | 119kN | 76.5kN | RPM | RPM | 30RPM | 深沟球轴承 | |
| 6215-2Z/VA208 | 75mm | 130mm | 25mm | 68.9kN | 49kN | RPM | RPM | 40RPM | 深沟球轴承 | |
| 6215-2Z/VA228 | 75mm | 130mm | 25mm | 68.9kN | 49kN | RPM | RPM | 80RPM | 深沟球轴承 | |
| 6214-2Z/VA201 | 70mm | 125mm | 24mm | 63.7kN | 45kN | RPM | RPM | 40RPM | 深沟球轴承 | |
